Single Point Platform Load Cell 100-1000kg NA106
NA106 is a high-capacity, off-center loading aluminum single point load cell. This Platform Design Load Cell is specially coated to assure durability in harsh environments. Capacities range from 100-10
Share to:
- Delivery Charge: Depend On Products Quantity and Weight*
- Inside Dhaka: 60 Taka
- Outside Dhaka :150 Taka
Item NO.:NA106
Product Orgin:China
Shipping Port:Xiamen
Payment:100% payment before shipment
Capacities:100-1000kg
Material:Aluminum Alloy
Dimension:188*63.5*60mm
Rated Output:2.0mV/V
Protection Class:PI66/PI67
Single Point Platform Load Cell NA106
NA106 is a high-capacity, off-center loading aluminum single point load cell. This Platform Design Load Cell is specially coated to assure durability in harsh environments. Capacities range from 100-1000 kg.
Key Features：
Wide range of capacities: 100kg-1000 kg
Potted and silicone sealed construction
Calibrated to national standards
Long term, reliable operation
Usage & Applications：
Weighing platforms up to 600mmx600mm
Bagging, filling and dosing systems
Checkweighers
Small buckets and hoppers
Big bag (FIBC) filling
Medical scales
NA106 Specification：
| Rated Capacities | 200,250,300,500,600,750,800（kg） |
| Rated Output | 2.0 mV/V±5% |
| Zero Balance | ±0.0200 mV/V |
| Non-linearity | 0.02 %R.O. |
| Hysteresis | 0.02 %R.O. |
| Repeatability | 0.02 %R.O. |
| 30mins Creep | 0.02 %R.O. |
| 30mins Return | 0.02 %R.O. |
| Safe Overload | 150 %R.O. |
| Ultimate Overload | 200 %R.O. |
| Temperature Effect On Output | 0.002 %R.O./℃ |
| Temperature Effect On Zero | 0.003 %R.O./℃ |
| Input Impedance | 410±15 Ω |
| Output Impedance | 350±5 Ω |
| Insulation Impedance | ≥5000 MΩ/(50VDC) |
| Recommended Excitation | 5~12 VDC |
| Maximum Excitation | 15 VDC |
| OperatingTemperatureRange | -20~60 ℃ |
| Construction | Aluminum Alloy |
| Protection Class | IP66 / IP67 |
| Cable | φ5×2m |
| Recommended Platform Size | 600×800 mm |
| Mode of Connection | Red（EXC+）,Black（EXC-）,Green（SIG+）,White（SIG-） |
