Low Profile Sensor Aluminum Load Cell NA10
NA10 is a low profile single point parallel beam load cell with aluminum alloy material and surface anodized. The Aluminum Load Cell is suitable for a wide range of weighing scales. It’s potted and silicone sealed construction, protected to IP66.
- Item NO.: NA10
- Product Orgin: China
- Shipping Port: Xiamen
- Payment: 100% payment before shipment
- Capacities: 30-200kg
- Material: Aluminum Alloy
- Dimension: 130*40*22mm
- Rated Output: 2.0mV/V
- Protection Class: PI66/PI67
Share to:
- Delivery Charge: Depend On Products Quantity and Weight*
- Inside Dhaka: 60 Taka
- Outside Dhaka :150 Taka
Low Profile Load Cell Sensor NA10 (30-200kg)
NA10 is a low profile single point parallel beam load cell with aluminum alloy material and surface anodized. The Aluminum Load Cell is suitable for a wide range of weighing scales. It’s potted and silicone sealed construction, protected to IP66.
Key Features：
High accuracy OIML approved
Calibrated to national standards
Aluminum alloy construction
Easy to install
Usage & Applications：
price computing scales
counting scales
weighing scales
retail scales
Dimension：
NA10 Specification：
| Rated Capacities | 40,60,100,200 (kg) |
| Rated Output | 2.0 mV/V±10% |
| Zero Balance | ±0.0200 mV/V |
| Non-linearity | 0.02 %R.O. |
| Hysteresis | 0.02 %R.O. |
| Repeatability | 0.02 %R.O. |
| 30mins Creep | 0.02 %R.O. |
| 30mins Return | 0.02 %R.O. |
| Safe Overload | 150 %R.O. |
| Ultimate Overload | 200 %R.O. |
| Temperature Effect On Output | 0.002 %R.O./℃ |
| Temperature Effect On Zero | 0.003 %R.O./℃ |
| Input Impedance | 410±15 Ω；1130±30 Ω |
| Output Impedance | 350±5 Ω； 1000±10 Ω |
| Insulation Impedance | ≥5000 MΩ/(50VDC) |
| Recommended Excitation | 5~12 VDC |
| Maximum Excitation | 15 VDC |
| OperatingTemperatureRange | -20~60 ℃ |
| Construction | Aluminum Alloy |
| Protection Class | IP66 / IP67 |
| Cable | φ4×0.5m |
| Recommended Platform Size | 350×400 mm |
| Mode of Connection | Red（EXC+）,Black（EXC-）,Green（SIG+）,White（SIG-） |
