Item NO.:NA1
Product Orgin:China
Shipping Port:Xiamen
Payment:100% payment before shipment
Capacities:3-50kg
Material:Aluminum Alloy
Dimension:130*30*22mm
Rated Output:2.0mV/V
Protection Class:PI66/PI67
Low Profile Load Cell NA1 (3-50kg)
NA1 is a low profile single point load cell with aluminum construction and surface anodized, suitable for a wide range of retail scales. This single point parallel beam load cell is available in the capacities: 3, 6, 10, 20, 35,50kg.
Key Features：
High accuracy OIML approved
Calibrated to national standards
Aluminum alloy construction
Compact Design
Easy to install
Long term, reliable operation
Usage & Applications：
price computing scales
counting scales
weighing scales
retail scales
NA1 Specification：
| Rated Capacities | 3~50 (kg) |
| Rated Output | 2.0 mV/V±10% |
| Zero Balance | ±0.0200 mV/V |
| Non-linearity | 0.02 %R.O. |
| Hysteresis | 0.02 %R.O. |
| Repeatability | 0.02 %R.O. |
| 30mins Creep | 0.02 %R.O. |
| 30mins Return | 0.02 %R.O. |
| Safe Overload | 150 %R.O. |
| Ultimate Overload | 200 %R.O. |
| Temperature Effect On Output | 0.002 %R.O./℃ |
| Temperature Effect On Zero | 0.003 %R.O./℃ |
| Input Impedance | 410±15 Ω；1130±30 Ω |
| Output Impedance | 350±5 Ω； 1000±10 Ω |
| Insulation Impedance | ≥5000 MΩ/(50VDC) |
| Recommended Excitation | 5~12 VDC |
| Maximum Excitation | 15 VDC |
| OperatingTemperatureRange | -20~60 ℃ |
| Construction | Aluminum Alloy |
| Protection Class | IP66 / IP67 |
| Cable | φ4×0.5m |
| Recommended Platform Size | 350×350 mm |
| Mode of Connection | Red（EXC+）,Black（EXC-）,Green（SIG+）,White（SIG-） |
