Low profile precision load cell weight sensor wholesale NA8
The NA8 is a precision load cell made with aluminum alloy material. The range capacities of Low profile load cell is from 60kg to 200kg, suitable for the pricing scale, counting scale and other electronic weighing scales.
Share to:
- Delivery Charge: Depend On Products Quantity and Weight*
- Inside Dhaka: 60 Taka
- Outside Dhaka :150 Taka
Item NO.:NA8
Product Orgin:China
Shipping Port:Xiamen
Payment:100% payment before shipment
Capacities:60-200kg
Material:Aluminum Alloy
Dimension:130*38*23mm
Rated Output:2.0mV/V
Protection Class:PI66/PI67
NA8 Weight Sensor Wholesale
The NA8 is a precision load cell made with aluminum alloy material. The range capacities of Low profile load cell is from 60kg to 200kg, suitable for the pricing scale, counting scale and other electronic weighing scales..
Key Features：
Low profile construction
Aluminum alloy material
Capacity: 60-200kg
Easy to install
Usage & Applications：
Pricing scales
Counting scales
NA8 Specification：
| Rated Capacities | 60，100，150，200（kg） |
| Rated Output | 2.0 mV/V±5% |
| Zero Balance | ±0.0200 mV/V |
| Non-linearity | 0.02 %R.O. |
| Hysteresis | 0.02 %R.O. |
| Repeatability | 0.02 %R.O. |
| 30mins Creep | 0.02 %R.O. |
| 30mins Return | 0.02 %R.O. |
| Safe Overload | 150 %R.O. |
| Ultimate Overload | 200 %R.O. |
| Temperature Effect On Output | 0.002 %R.O./℃ |
| Temperature Effect On Zero | 0.003 %R.O./℃ |
| Input Impedance | 410±15 Ω |
| Output Impedance | 350±5 Ω |
| Insulation Impedance | ≥5000 MΩ/(50VDC) |
| Recommended Excitation | 5~12 VDC |
| Maximum Excitation | 15 VDC |
| OperatingTemperatureRange | -20~60 ℃ |
| Construction | Aluminum Alloy |
| Protection Class | IP66 / IP67 |
| Cable | φ4×0.5m |
| Recommended Platform Size | 400×400 mm |
| Mode of Connection | Red（EXC+）,Black（EXC-）, Green（SIG+）,White（SIG-） |
