Kjeldahl Distillation Unit K9840 – Hanon China

Kjeldahl Distillation Unit

Brand: Hanon

Model: K9840

Country of Origin: China

Kjeldahl Distillation Unit  K9840 – Hanon China

Characteristics:

  • Display: 4.3-inch color screen.
  • Manual/Automatic mode changeover free.
  • Automatic Alkali pipeline washing function.
  • Automatic or manual filling mode is optional according to test need.
  • Distillation time can be edited freely, and automatic alarming upon completion.
  • Automatic cleaning of control system and distiller, ensuring high measurement accuracy.
  • Intelligent design of nitrogen tube peripheral facilities including safety designs and displacement hints.
  • Intelligent cooling water control system achieves cooling water control and test.
  • Emergency stop operation is able to deal with unexpected accidents.
  • Automatic fault detection and intelligent audible and visual alarm system are available.
  • Calibration Function: Dilution water calibration, Alkali solution calibration, Boric acid solution calibration, washing flow calibration.
  • Safety door, digestion tube and cooling water conditions are displayed in real time when running.
  • Testing model is built-in, for detecting most functions condition.

Features:

  • Automatic accurate distribute alkali and boric acid solution.
  • Perfect safety protection system gives distiller and tubes measurement and protection against over temperature and over pressure.
  • Calibration Function: Dilution water calibration, Alkali solution calibration, Boric acid solution calibration, Washing flow calibration.
  • Safety door, digestion tube and cooling water conditions are displayed in real time when running.

Technical data:

Measuring range0.1mg ~240mg N
Recovery≧99.5%
Sample capacitysolid≦6g/sample, liquid≦16mL/sample
Distillation speed3-6min/sample
Cooling water consumption1.5L/min
Operating modeManual/automatic mode
Display modes4.3″ LCD screen
Power supply220VAC±10%, 50Hz
Power1.3KW
Net weight30Kg
Dimensions400mm×385mm×735mm
