Description
Smart Sensor AR932 Film Coating Thickness Gauge
FEATURES:
A coating thickness gauge is used to measure the coating wall of metals and other materials. It uses digital process technology, accurate, and light. Model: AR932, Brand: Smart Sensor, Made in China.
SPECIFICATIONS
|
Measuring range |
0~1800ฮผm |
|
Measuring Principle |
Magnetic Induction & Eddy current |
|
Accuracy |
ยฑ(1.8%umยฑ2um)(0-500um) ; ยฑ(2.2%umยฑ2um) (500-1500um) |
|
Resolution |
0.1ฮผm / 1ฮผm |
|
Backlight Display |
โ |
|
Battery Indication |
โ |
|
Zero / Twoย Poin /ย Basic correction |
โ |
|
Alarm Buzzer |
โ |
|
Single / Continuous / Standard Deviation Measurement |
โ |
|
Data Storage & Recall |
โ |
|
Data Storage |
20 groups |
|
Max & Min Measuring |
โ |
|
AVG & DFR Measuring |
โ |
|
Metric / Imperial Switchable |
โ |
|
Data Analysis |
โ |
|
Operating Condition |
0โ~50โ(without strong magnetic) |
PACKING INFORMATION
|
Power |
2*1.5V AAA battery |
|
Product Net Weight |
75g |
|
Product Size |
119*50*30mm |
|
Packing |
Gift ย Box |
|
Standard Quantity Per Carton |
40 |
|
Standard Carton Size |
52.5*40*49cm |
|
Standard Carton Gross Weight |
20KG |
