Fat Analyzer SOX406

Description

Scope of application:

SOX406 Fat Analyzer can quickly separate one substance from solid or semi-solid mixtures, can determine the soluble organic compounds contained in foods, feeds, medicines, soil, sludge, polymers, fiber products, petrochemical products, detergents, rubber, plastics, and other materials.

Characteristics:

• Integral metal heating, while the scope and high precision of temperature control
• The electric circuit is isolated from the extraction space, ensuring devices security
• Over-temperature alarming and timer reminding functions are available
• The timer circuit is isolated from the extraction space, ensuring device security
• Triple alarms i.e. sound, light, LCD screen word prompts are available
• Abundant interface contents give simultaneous display of given temperature, actual temperature, given time, and heating time
• The lifting connection of linear bearing conduction technique gives smooth and comfortable lifting operation
• Intelligent man-machine dialogue control system
• Exclusive air insulation technique leaves the case in room temperature, has thermal insulation and temperature maintenance two functions
• 3″ LCD screen and microcomputer control system are adopted

• Technical data:

  Temperature range	Room temperature +5℃～280℃
  Measuring range	0～100%
  Temperature accuracy	±1℃
  Sample weight	0.5～15g(generally 2~5g,depending on sample)
  Capacity per batch	6pcs/batch
  Solvent cup volume	80mL
  Solvent recovery	≥80%
  Shortened extraction time	20~80%
  Power supply	220VAC±10%, 50Hz
  Power	1KW
  Dimensions	650mm×320mm×715mm
  Net Weight	35Kg
