Aluminum alloy Tension Load Cell for textile machine NA125
NA125 is one of aluminum alloy tension load cell made with low capacities 2kg. The tension sensor is suitable for the textile machine.
Share to:
- Delivery Charge: Depend On Products Quantity and Weight*
- Inside Dhaka: 60 Taka
- Outside Dhaka :150 Taka
Item NO.:NA125
Product Orgin:China
Shipping Port:Xiamen
Payment:100% payment before shipment
Capacities:2kg
Material:Aluminum Alloy
Dimension:29.8*43.4*10mm
Rated Output:1.0mV/V
Protection Class:IP65 / IP66
Aluminum alloy Tension Load Cell NA125 (2KG)
Hope Technologic (Xiamen) Co., Ltd. NA125 is one of aluminum alloy tension load cell made with low capacities 2kg. The tension sensor is suitable for the textile machine.
Key Features：
Aluminum alloy construction
Capacity: 2 KG
Easy to install, stable & reliable
Usage & Applications：
Hopper scales
Crane scales
Tension control and machine testing
Batching systems, blending & mixing systems, belt scales,etc
NA125 Specification：
| Rated Capacities | 2（kg） |
| Rated Output | (1.05~1.3)mv/v |
| Zero Balance | ±0.0200 mV/V |
| Non-linearity | 0.03 %R.O. |
| Hysteresis | 0.03 %R.O. |
| Repeatability | 0.03 %R.O. |
| 30mins Creep | 0.05 %R.O. |
| 30mins Return | 0.05 %R.O. |
| Safe Overload | 150 %R.O. |
| Ultimate Overload | 200 %R.O. |
| Temperature Effect On Output | 0.005 %R.O./℃ |
| Temperature Effect On Zero | 0.005 %R.O./℃ |
| Input Impedance | 410±15 Ω |
| Output Impedance | 350±5 Ω |
| Insulation Impedance | ≥5000 MΩ/(50VDC) |
| Recommended Excitation | 5~12 VDC |
| Maximum Excitation | 15 VDC |
| OperatingTemperatureRange | -20~60 ℃ |
| Construction | Aluminum Alloy |
| Protection Class | IP65 / IP66 |
| Cable | Φ3*8cm(cable with connector) |
| Recommended Platform Size | |
| Mode of Connection | Red（EXC+）,Black（EXC-）, Green（SIG+）,White（SIG-） |
