Aluminum Alloy S Beam force Sensor NS7
NS7 is S beam force sensor with good protection and high accuracy. The Aluminum S beam construction load cell is suitable for applications such as hanging scale and hopper scale with low capacity from10kgto20kg.
Share to:
- Delivery Charge: Depend On Products Quantity and Weight*
- Inside Dhaka: 60 Taka
- Outside Dhaka :150 Taka
Item NO.:NS7
Product Orgin:China
Shipping Port:Xiamen
Payment:100% payment before shipment
Capacities:10-20kg
Material:Aluminum Alloy
Dimension:63.5*50.8*14.7mm
Rated Output:2.0mV/V
Protection Class:IP66 / IP67
Aluminum alloy Tension Load Cell NS7 (10-20 KG)
NS7 is S beam force sensor with good protection and high accuracy. The Aluminum S beam construction load cell is suitable for applications such as hanging scale and hopper scale with low capacity from10kgto20kg.
Key Features：
Low profile
Aluminum alloy construction
Capacity: 10-20 KG
Easy to install, stable & reliable
Usage & Applications：
Hopper scales
Crane scales
Tension control and machine testing
NS7 Specification：
| Rated Capacities | 10，20 (kg) |
| Rated Output | 2.0 mV/V±0.25% |
| Zero Balance | ±0.0200 mV/V |
| Non-linearity | 0.03 %R.O. |
| Hysteresis | 0.03 %R.O. |
| Repeatability | 0.03 %R.O. |
| 30mins Creep | 0.03 %R.O. |
| 30mins Return | 0.03 %R.O. |
| Safe Overload | 150 %R.O. |
| Ultimate Overload | 200 %R.O. |
| Temperature Effect On Output | 0.002 %R.O./℃ |
| Temperature Effect On Zero | 0.003 %R.O./℃ |
| Input Impedance | 390±15 Ω |
| Output Impedance | 350±5 Ω |
| Insulation Impedance | ≥5000 MΩ/(50VDC) |
| Recommended Excitation | 5~12 VDC |
| Maximum Excitation | 15 VDC |
| Operating Temperature Range | -20~60 ℃ |
| Construction | Aluminum Alloy |
| Protection Class | IP66 / IP67 |
| Cable | φ5×2 m |
| Recommended Platform Size | |
| Mode of Connection | Red（EXC+）,Black（EXC-）,Green（SIG+）,White（SIG-） |
