Postage scale Load Cell low profile weighing sensor NA33
The NA33 is a low profile load cell and can be used individually in postage scales. The moment insensitive design allows for simple installations.
Share to:
- Delivery Charge: Depend On Products Quantity and Weight*
- Inside Dhaka: 60 Taka
- Outside Dhaka :150 Taka
Item NO.:NA33
Product Orgin:China
Shipping Port:Xiamen
Payment:100% payment before shipment
Capacities:15-80kg
Material:Aluminum Alloy
Dimension:56.5*10*18mm
Rated Output:1.5 mV/V
Protection Class:PI65
Postage scale Load Cell NA33
The NA33 is a low profile load cell and can be used individually in postage scales. The moment insensitive design allows for simple installations.
Key Features：
Low profile and capacity
Aluminum construction
Capacity: 15-80kg
Accuracy:0.02%R.O.
Usage & Applications：
Kitchen scales
Portable scales
Electronic scales
NA33 Specification：
| Rated Capacities | 15，20，30，40，60，80（kg） |
| Rated Output | 1.5 mV/V±10% |
| Zero Balance | ±0.0200 mV/V |
| Non-linearity | 0.02 %R.O. |
| Hysteresis | 0.02 %R.O. |
| Repeatability | 0.02 %R.O. |
| 30mins Creep | 0.02 %R.O. |
| 30mins Return | 0.02 %R.O. |
| Safe Overload | 150 %R.O. |
| Ultimate Overload | 200 %R.O. |
| Temperature Effect On Output | 0.01 %R.O./℃ |
| Temperature Effect On Zero | 0.05 %R.O./℃ |
| Input Impedance | 1115±10%Ω |
| Output Impedance | 1000±10% Ω |
| Insulation Impedance | ≥2000 MΩ/(50VDC) |
| Recommended Excitation | 5~12 VDC |
| Maximum Excitation | 15 VDC |
| OperatingTemperatureRange | -20~60 ℃ |
| Construction | Aluminum Alloy |
| Protection Class | IP65 |
| Cable | φ0.8×0.6m |
| Recommended Platform Size | 300×300 mm（4PCS/Set） |
| Mode of Connection | Red（EXC+）,Black（EXC-）, Green（SIG+）,White（SIG-） |
