Item NO.:NA21
Product Orgin:China
Shipping Port:Xiamen
Payment:100% payment before shipment
Capacities:500-1500kg
Material:Steel Alloy
Dimension:200*50*40mm
Rated Output:2.0mV/V
Protection Class:PI66/67
Steel Alloy Single Point Load Cell NA21
NA21 is a potted and silicone sealed load cell. The strain gauge weight sensor is manufactured from steel alloy and characterized with high accuracy and linearity.
Key Features：
Calibrated to national standards
Steel alloy construction
Compact Design
Easy to install
Long term, reliable operation
Usage & Applications：
Platform scales
Bench scales
Retail scales
Variety of other applications
Dimension：
NA21 Specification：
| Rated Capacities | 300, 500, 1000, 1200, 1500(kg) |
| Rated Output | 2.0 mV/V±10% |
| Zero Balance | ±0.0200 mV/V |
| Non-linearity | 0.02 %R.O. |
| Hysteresis | 0.02 %R.O. |
| Repeatability | 0.02 %R.O. |
| 30mins Creep | 0.02 %R.O. |
| 30mins Return | 0.02 %R.O. |
| Safe Overload | 150 %R.O. |
| Ultimate Overload | 200 %R.O. |
| Temperature Effect On Output | 0.002 %R.O./℃ |
| Temperature Effect On Zero | 0.003 %R.O./℃ |
| Input Impedance | 390±15 Ω |
| Output Impedance | 350±5 Ω |
| Insulation Impedance | ≥5000 MΩ/(50VDC) |
| Recommended Excitation | 5~12 VDC |
| Maximum Excitation | 15 VDC |
| OperatingTemperatureRange | -20~60 ℃ |
| Construction | Steel Alloy |
| Protection Class | IP66 / IP67 |
| Cable | φ5×2.5m |
| Recommended Platform Size | 700×800 mm |
| Mode of Connection | Red（EXC+）,Black（EXC-）,Green（SIG+）,White（SIG-） |
