Highland® Portable Precision Balances: HCB 123

Hardware

• Balances stack efficiently and safely to save space (120mm pan size only)
• Colour-coded keys facilitate quick recognition of the most frequently used buttons
• Dual tare keys operate with either the left or right hand
• Level indicator and adjustable feet ensure proper balance setup for optimum weighing results
• Security slot for optional Kensington-type lock and cable to help prevent theft
• Large, grade 304 stainless steel pan allows easy cleaning
• Solid ABS housing is durable for industrial use
• Three-point ShockProtect® feature helps prevent overload damage to internal components
• Hook included for weighing below the balance
• HandiCal® internal calibration eliminates need for external weight set
• USB and RS-232 interfaces provide speedy communication with computers and printers

Software

• Audible overload alarm warns when capacity is exceeded
• External calibration allows for verification and adjustment with weights
• Selectable digital filtering helps minimise effects of vibration and disturbances
• Parts counting with preset sample sizes
• Memory accumulation totals results
• Zero-tracking feature ensures display returns to zero reading

Display

• Vivid, backlit LCD easily visible in any lighting conditions
• Programmable backlight can be set to “always on,” “always off” or “light only when weighing”
• Capacity tracker built into display for easily monitoring possible overloads

Power

• AC adapter included
• Rechargeable battery included for operation almost anywhere
• Programmable auto power-off to save energy


  HCB 123 Specifications

  Capacity

  120g

  Readability

  0.001g

  Repeatability

  0.002g

  Weighing Units

  g, lb, oz, N, GN, ct, dr, dwt, mm, ozt, T, tl.H, tl.S, tl.T

  Calibration

  External calibration / Internal manual calibration

  Stabilization Time

  2.0

  Pan Size

  120mm ø

  Linearity

  0.003g

  Power Supply

  12VDC 50/60Hz 800mA adapter / Internal rechargeable battery

  Construction

  ABS plastic

  Interface

  RS-232, USB

  Operating Temperature

  0° to 40°C

  Net Weight

  2kg

  Overall Dimensions

  174x252x80mm (wxdxh)

  Electrical Safety Mark

  CE, cUL

  Approvals

  N/A

  Display Digit Height

  18mm

  Battery Life (Hours)

  24.0
